LOTUS EUROPA S1/S2 COMBINED PARTS MANUALSection ME -- Electrical -- Taillights S1B and S2Lotus Europa Central -- Tech Specifications -- S1/S2 Parts Home -- Manuals Home -- Feedback |
|---|
| Click here to open a new window containing a searchable PDF copy. (145K) |
 |  |  |  |  |  |  |  |  |  | Notes Bulletin Reference | |||
| 1 | 050M6059 | 1 | 1 | Rear Lamp Assembly LH | From Chassis No. 0542 - More Info - | ||||||||
| 1 | 050M6060 | 1 | 1 | Rear Lamp Assembly RH | From Chassis No. 0542 - More Info - | ||||||||
| 1 | 050M6077 | 1 | Rear Lamp Assembly LH | From Chassis No. 1066 to ? - More Info - | |||||||||
| 1 | A054M6081 | 1 | Rear Lamp Assembly LH | From Chassis No. 7001030001R - More Info - | |||||||||
| 1 | 050M6079 | 1 | Rear Lamp Assembly RH | From Chassis No. 1066 to ? - More Info - | |||||||||
| 1 | A054M6080 | 1 | Rear Lamp Assembly RH | From Chassis No. 7001030001R - More Info - | |||||||||
| 2 | 050M6061 | 1 | 1 | Lens LH | From Chassis No. 0542 | ||||||||
| 2 | 050M6062 | 1 | 1 | Lens RH | From Chassis No. 0542 | ||||||||
| 2 | 050M6079 | 1 | Lens LH | From Chassis No. 1066 | |||||||||
| 2 | 050M6080 | 1 | Lens RH | From Chassis No. 1066 | |||||||||
| 2 | A054M6095 | 1 | Lens LH | From Chassis No. 7001030001R | |||||||||
| 2 | A054M6096 | 1 | Lens RH | From Chassis No. 7001030001R | |||||||||
| 3 | A036M6331 | 2 | 2 | 2 | 2 | Bulb (380) - Stop -Tail | From Chassis No. 0542 - More Info - | ||||||
| 4 | A036M6329 | 2 | 2 | 2 | 2 | Bulb (382) - Flasher | From Chassis No. 0542 - More Info - | ||||||
| 5 | A036M6332 | 2 | 2 | 2 | 2 | Bulb (272) - Reverse | From Chassis No. 0542 - More Info - | ||||||
| XUFB0308 | 6 | 6 | 6 | 6 | Bolt - Rear Lamp Mounting | From Chassis No. 0542 | |||||||
| A03W1606 | 6 | 6 | 6 | 6 | Washer - Rear Lamp Mounting | From Chassis No. 0542 | |||||||
| 036M0127 | 2 | Fuse Unit - West Germany only | |||||||||||
| A050M6167 | 2 | Fuse 5 amp. |
